HCL 1200 Top (Code: 10-1184)

Hits:

2247

Zoom image



Technical specifications

Distance between centers	1200 mm
Working diameter
- over guideway	560 mm
- over support	450 mm
Spindle speed, stepless	0 - 1200 rpm
	0 - 3200 rpm
Speed steps	stepless, 2 steps
Spindle thread	M 33 x 3,5 mm
Tailstock
Taper of tailstock sleeve	MK 2
Travel of tailstock sleeve	110 mm
Motor power output S1 100%	1,5 kW (2,0 HP)
Motor power input S6 40%	2,2 kW (3,0 HP)
Voltage	230 V
Machine dimension (W x D x H)	2100 x 550 x 1300 mm
Weight approx.	212 kg

Properties

• Quick clamping lever ensures fast clamping of tailstock to machine bed
• Outboard turning attachment optionally available for processing of oversize workpieces
• Includes steel tool rest, easily adjustable for various workpiece diameters
• Heavy cast-iron construction eliminates vibrations
• Digital display allows for convenient adjustment of speed settings
• Comes complete with right and left turning device
• Delta-frequency inverter ensures variable speed adjustment with optimal torque
• Precisely bedded spindle ensures high concentricity
• Smooth running, powerful DC drive, steplessly adjustable

Standard accessories

• Tool rest 360 mm
• Face plate 150 mm
• Live center
• Spore drive center
• Frequency inverter
• Tools
