TK 250 F (Code: 09-1070)

Hits:

3182

Zoom image

Technical specifications

Table size	800 x 520 mm
Sliding table	410 x 710 mm
Cutting length	1230 mm
Max. sawblade diameter	254 x 30 mm
Max. cutting height 90° / 45°	82 / 54 mm
Travel of sawblade	225 mm
Cutting width on rip fence	730 mm
Table height	900 mm
Table extension	800 x 320 mm
Square table	600 x 410 mm
Speed main sawblade	4000 rpm
Dust extraction outlet Ø	100 mm
Motor power output S1 100%	1,5 kW (2,0 HP)
Motor power input S6 40%	2,1 kW (2,85 HP)
Voltage	230 V
Machine dimension (W x D x H)	2020 x 2300 x 1200 mm
Weight approx.	175 kg



Properties

• Complete with user-friendly sliding table with a surface of 410 x 710 mm
• Extractable telescopic fence (up to 2000 mm) mountable at front or rear of square table, steplessly tiltable from 90º to 45º
• Mitre fence either useable on right or left of sawblade, suitable for angle cuts up to 45º
• Ergonomically arranged handwheels allow for setting of saw unit
• Solid grey cast-iron table with T-slots on right and left of sawblade
• Includes table extension on the right for better support of oversize boards
• Solid and easily adjustable saw unit, tiltable from 90º to 45º
• Square table ensures convenient machining of large boards

Standard accessories

• Carbide sawblade 254 x 3,0 x 30 mm / 36T
• Protective cover with dust extraction outlet
• Connector tube with Y-piece
• Mitre fence with eccentric holder
• Table extension right
• Extractable telescopic fence
• Square table
• Radial-pull sawing device
• Push stick
• Tools
