LBM 350 T (Code: 10-1011)

Hits:

2187

Table size	595 x 315 mm
Table extension	2x 200 x 220 mm
Table height	830 mm
Max. drill depth	220 mm
Drill width	340 mm
Height adjustment	145 mm
Drill head tiltable right / left	-60° to +60°
Speed	1400 / 2850 rpm
Westcott drill chuck	0 - 20 mm
Motor power	1,5 / 1,9 kW (2,0 / 2,6 HP)
Voltage	400 V
Machine dimension (W x D x H)	1200 x 1050 x 1300 mm
Weight approx.	240 kg

Maintenance-free linear guiding allows for feed of drill depth
Quick lift system allows for effi cient, economical processing without time-consuming winding of crank
Smooth, stepless height setting of drill head features fi ne adjustment and gas pressure cylinder for counter balance
Cross travel and height adjustment features scales and adjustable fences
Robust steel construction eliminates vibrations
Drill depth adjustable via scale and fence
Height adjustment of drill head can be altered throughout vertical slotting
Large grey cast iron table with polished surface
Westcott drill chuck 0 - 20 mm complete with protective cover
