LBM 150 P - 230V (Code: 10-0998)

Hits:

2147

Zoom image

Technical specifications

Table size	500 x 200 mm
Table height	760 - 900 mm
Max. drill depth 90°	150 mm
Drill width	300 mm
Height adjustment	140 mm
Speed	2850 rpm
Westcott drill chuck	0 - 16 mm
Dust extraction outlet	100 mm
Motor power output S1 100%	2,2 kW (3,0 HP)
Motor power input S6 40%	3,0 kW (4,0 HP)
Voltage	230 V
Machine dimension (W x D x H)	770 x 920 x 1245 mm
Weight approx.	102 kg

Properties

• Complete with Westcott drill chuck 0 - 16 mm with cover
• Eccentric holder for secure fastening of workpiece comes standard
• Ergonomically positioned lever allows for one handed operation of work table
• Motor protective switch in accordance with IP 54 standards with undervoltage release
• Precise roller guiding ensure accurate movement of work table
• Powerful motor guarantees optimal performance
• Multiple holes are easy to achieve with the rotor group (part of standard equipment)

Standard accessories

• 4-size rotor group with grid spacing 16 / 20 / 22 / 25 mm
• Westcott drill chuck 0 - 16 mm
• 1 pc. eccentric holder
• Mitre fence with guide
• Left and right turning
• Digital readout for table height adjustment
• Machine base with tool shelf
