PT 410 (Code: 08-1061)

Hits:

2241

Zoom image

Technical specifications

Planer
Planing width	410 mm
Table length	1600 mm
Table height	920 mm
Shaft rotation speed	4000 rpm
Cutter knives	4 pcs.
Planer shaft diameter	95 mm
Planer fence	1120 x 130 mm
Fence tiltable	90° to 45°
Max. cutting depth	5 mm
Thicknesser
Table length	750 mm
Working width	410 mm
Working thickness, min./max.	4 - 220 mm
Max. cutting depth	2,5 mm
Feed speed	8 m/min
Dust extraction outlet	100 mm
Motor power output S1 100%	3,0  kW (4,0 HP)
Motor power input S6 40%	4,2 kW (5,7 HP)
Voltage	400 V
Machine dimension (L x W x H)	1610 x 1050 x 1100 mm
Weight approx.	340 kg

Properties

• Solid planer fence with prism guide, tiltable from 90º to 45º
• Maintenance-free 4-knife cutterblock features HSS-quality cutter knives
• Tiltable planer tables for quick conversion to thicknessing
• Both planer tables feature fine adjustment and table slots to reduce noise levels
• Integrated tiltable dust hood – extraction outlet 100 mm
• Feed can be switched off when planing
• Switch-plug-combination with motor brake
• Torsion-free, grey cast-iron planer tables ensure best results
• Cutterblock guard in accordance with CE-standards guarantees high level of safety
• Thicknessing table runs on central column and is well supported for high accuracy

Standard accessories

• Cutter knives in HSS-quality
• Knife gauge
• Switch-plug-combination
• Push handle
