AD 260 (Code: 08-1052)

Hits:

3157

Zoom image

Technical specifications

Planer
Planing width	250 mm
Table length	1090 mm
Table height	835 mm
Shaft rotation speed	4000 rpm
Cutter knives	3 pcs.
Planer shaft diameter	75 mm
Planer fence	715 x 130 mm
Fence tiltable	90° to 45°
Max. cutting depth	3 mm
Thicknesser
Table length	600 mm
Working width	250 mm
Working thickness, min./max.	5 - 185 mm
Max. cutting depth	2,5 mm
Feed speed	4,8 m/min
Dust extraction outlet	100 mm
Motor power output S1 100%	2,0 kW (2,7 HP)
Motor power input S6 40%	2,8 kW (3,8 HP)
Machine dimension (L x W x H)	1150 x 800 x 1000 mm
Weight approx.	173 kg

Properties

• Planing tables tilt to the back of the machine to keep space requirements to a minimum
• Precisely bedded, smooth running 3-knife cutterblock guarantees optimal results
• Integrated, tiltable dust hood, extraction outlet 100 mm
• Simultaneous tilting of planing tables to achieve maximum comfort
• Thicknessing table feed can be switched off when planing
• Hard-anodized aluminium planing fence, tiltable from 90° to 45°
• Thicknessing table with central column and support allow precise planing
• Torsion-free, cast iron planing tables guarantees best results
• Numerous safety devices: On/Off switch with undervoltage release, cutterblock cover in accordance with CE, limit switch to avoid accidental machine start,...

Standard accessories

• Cutter knives in HSS-quality
• Knife gauge
• Push handle
